Review Summary
The Vaporesso Armour Ultra pairs a 5500mAh internal battery with 100W AXON chipset performance and triple-certified military and waterproofing protection, targeting experienced sub-ohm vapers who want all-day endurance without external cells. The GTi Dual Mesh coil platform and top-airflow iTank T deliver consistent DTL performance across the wattage range. At 256g it is a substantial device, and the internal battery format means it suits vapers who prioritise endurance and protection over compact portability.
The Armour Ultra is built to a protection standard that few consumer vape devices match. The IP68 rating covers submersion in water beyond 1 metre for extended periods. IP69K goes further, certifying resistance to high-pressure, high-temperature water jets of the kind used in industrial cleaning. MIL-STD-810H is a United States military specification covering shock, vibration, humidity, and temperature extremes, and the Armour Ultra has been tested against drops of up to 1.2 metres. Taken together, these three certifications position the device at the upper end of what is available for durability in the vape mod category.
The outer chassis is wrapped in a TPU armoured coating that provides grip and impact absorption across the full surface of the device. The texture is consistent and holds its character through extended handling, and the coating sits flush with the control face rather than adding uncomfortable bulk around the fire button. The Uni-Lock system requires a deliberate press to engage the power button, reducing the risk of accidental activation in a bag or deep pocket. The 0.96-inch TFT colour display sits on the control face and shows wattage, output mode, battery level, coil resistance, and puff data clearly at typical arm's length viewing distance.
The iTank T uses a top-airflow configuration, drawing air in through ports above the coil rather than at the base. This design keeps the airflow path away from the e-liquid supply in the tank body, which removes the leak pathway that makes bottom-airflow tanks more prone to seeping during transport or when left on a surface. The top-fill mechanism opens without tools and seals securely. The tank ships with 2ml capacity in the UK version, in line with UK TPD regulations that cap tank capacity at 2ml for TPD-compliant products. For background on Vaporesso's broader product range and how the Armour series sits within it, the Vaporesso brand overview covers the full lineup.
At 256g the Armour Ultra is a substantial device. It does not fit comfortably in a standard trouser pocket for extended carry and is better suited to a bag, a jacket pocket, or desk use alongside a desk or work environment where its size is not a constraint. The weight and dimensions are a direct consequence of the 5500mAh cell and the armoured chassis, and for the audience the device targets, those are deliberate trade-offs rather than oversights.
The AXON chipset drives the Armour Ultra from a minimum usable wattage up to the 100W ceiling with a firing response that registers quickly after the button press. Pulse Mode maintains a consistent effective power level by adjusting the output in short pulses to compensate for battery voltage drop as the cell depletes, which keeps the draw character more stable across a full tank than standard fixed-wattage output. F(t) Mode modulates output over the duration of each draw, delivering higher power at the start and tapering off, which Vaporesso describe as increasing flavour density. Both modes are accessible through the display menu and give experienced sub-ohm vapers a meaningful choice in output behaviour beyond simple wattage adjustment.
The GTi Dual Mesh coil platform is the foundation of the tank's performance. The 0.2Ω dual mesh coil is the primary DTL option, operating at higher wattage for warmer, denser vapour production. The 0.4Ω dual mesh coil is an RDTL option suited to slightly lower wattage and a moderately less open draw, and is included in the box as a spare alongside the pre-installed 0.2Ω coil. COREX technology across both coils is designed to extend coil lifespan by improving heat distribution through the mesh element, reducing hot spots that accelerate coil degradation. Browse the Vaporesso coils range for all compatible GTi replacement options when a coil change is needed.
This is a dedicated sub-ohm and DTL device. It is not suited to MTL vaping at any wattage setting, and nicotine salts are not appropriate for use in either the 0.2Ω or 0.4Ω coils at the wattages this device operates at. Sub-ohm vaping at high wattage delivers a large volume of vapour per draw, and nicotine at 10mg or above produces an uncomfortable throat hit at DTL wattages. High-VG freebase e-liquid at 3mg or 6mg is the correct choice for both GTi coils. A 70/30 VG/PG blend or higher suits the 0.2Ω coil well. The broader e-liquid collection at WizVape includes a wide range of high-VG freebase options at low nicotine strengths suited to this kit.
Coil priming is important before first use. Dropping a few drops of e-liquid directly onto the exposed cotton of a new coil, then filling the tank and leaving it to stand for five to ten minutes, allows the mesh element to saturate fully before the first draw. Taking a dry hit on an unprimed sub-ohm coil will burn the cotton and shorten the coil's lifespan significantly, so this step should not be skipped. The coil finder tool can help confirm which GTi coil variant suits a specific vaping preference if you are considering different options beyond the two included in the kit.
The 5500mAh internal battery is the defining specification of the Armour Ultra and the primary reason to choose this device over a mod that uses external cells. At 100W maximum output with the 0.2Ω coil, the capacity is sufficient for a full day of regular sub-ohm vaping for most users, and at moderate wattage on the 0.4Ω coil the endurance extends further. The practical advantage over a single 21700 external-battery mod is considerable. A typical high-capacity 21700 cell offers around 4000mAh to 5000mAh under real-world conditions, and at sustained high wattage a single-battery mod may need a mid-day cell swap. The Armour Ultra removes that requirement for most daily use scenarios.
The trade-off for the internal battery is the absence of the option to swap in a fresh cell when the charge runs out. External battery mods allow a vaped-out cell to be replaced in seconds with a charged spare. The Armour Ultra requires a USB-C charge, and while the fast-charge input at DC 9V/2A delivers meaningfully faster replenishment than standard 5V charging on a 5500mAh cell, a full charge from flat takes considerably longer than swapping a battery. Vapers who want to cover sessions far from a charging point should plan around carrying a power bank or ensuring the device is fully charged before extended use. As with all lithium-ion batteries, using a quality cable and charger and not leaving the device charging unattended or overnight for extended periods is good practice for battery longevity.
Battery level is displayed on the 0.96-inch TFT screen, giving a clear readout rather than the LED indicator common to smaller devices. This makes it easy to monitor remaining capacity accurately rather than interpreting colour changes or pulse patterns. The screen also displays current resistance, wattage, and output mode, keeping all relevant operational data visible at a glance. For vapers looking to pick up accessories or replacement cables to cover charging options in different locations, the vape deals section and vape kit bundles at WizVape include options across the Vaporesso range.
For vapers accustomed to external-battery mods, the fixed internal cell is the most significant adjustment. The convenience of the Armour Ultra's configuration is real: no separate charger for cells, no battery safety concerns around transport, no need to buy and maintain a set of external batteries. Whether that convenience outweighs the absence of hot-swap capability depends on a vaper's usage pattern and how often they are away from a charging point for extended periods.
The Armour Ultra is aimed at experienced sub-ohm vapers, and the control set reflects that. The AXON chipset menu gives access to wattage adjustment, output mode selection between standard, Pulse, and F(t) modes, and the usual safety and protection settings. Navigation uses the fire button and adjustment controls in a standard three-button layout, and the TFT display makes menu items readable without the squinting required on smaller screens. Vapers who have used any regulated mod will find the interface familiar within a few minutes of use. Those new to sub-ohm vaping will face a steeper learning curve, and the Armour Ultra is not the right first device for someone stepping up from a pod kit without intermediate experience.
The Uni-Lock button system requires a specific press pattern to engage and fire, which prevents accidental activation in a bag or coat pocket. This is a practical feature on a 100W device, where an accidental fire against a bag lining could overheat a coil and waste e-liquid. The top-fill mechanism on the iTank T is one of the more user-friendly aspects of the kit. The fill port opens cleanly, accepts standard nozzle-tip bottles without requiring the tank to be removed from the mod, and seals securely without requiring excessive force. The extra glass tube included in the box is a useful addition, covering the risk of the primary tube breaking during regular use.
Coil installation is a push-and-lock process that seats the GTi coil securely in the tank base. The pre-installed 0.2Ω coil reads correctly on the screen immediately on first use, and switching to the spare 0.4Ω coil is a simple tank base removal and coil swap. The device prompts for wattage confirmation when a new coil resistance is detected, which prevents accidentally running a fresh coil at an inappropriate output. For vapers who are unsure which coil suits their vaping style, the coil finder tool provides guidance based on preferred draw and e-liquid type.
USB-C charging via the port on the base of the device works with any USB-C cable capable of carrying the 9V/2A fast charge input. The display shows charging progress accurately, which removes any uncertainty about how long a charge will take to complete. The overall experience of the Armour Ultra in daily use rewards users who know what they are doing with a reliable, capable device that requires no improvisation. It is not a device for casual or intermittent use by someone who does not understand wattage, coil resistance, and e-liquid selection for sub-ohm vaping.
The Vaporesso Armour Ultra is built for experienced sub-ohm and DTL vapers who want the endurance of a high-capacity internal battery in a fully protected chassis. It suits vapers who use their device in environments where durability matters: outdoor work, active use, or simply situations where a device is likely to encounter water, dust, or impacts that would damage a standard vape mod. The triple certification across IP68, IP69K, and MIL-STD-810H is not decorative. For vapers who have previously damaged mods through water exposure or drops, the Armour Ultra removes that failure point.
It also suits vapers who currently use a single-external-battery mod and find themselves needing a mid-day charge or cell swap. The 5500mAh internal battery covers more ground per charge than a single high-capacity 21700 under real-world high-wattage use, and the USB-C fast charge input reduces the time needed to top up when the battery does run down. For vapers who have already explored the Vaporesso range and want the Armour series' durability proposition at its most capable, the full Vaporesso collection provides the wider context. The complete vape kits range at WizVape covers options across brands if you want to compare before deciding.
The Armour Ultra is not the right choice for MTL vapers, pod kit users, or anyone who uses nicotine salts. The device operates at wattages where MTL vaping is impractical and where nicotine at 10mg or above produces an uncomfortable experience. It is not a discreet or pocket-friendly device, and vapers who prioritise compact carry will find the 256g weight and dimensions limiting. The internal battery also means that as the cell ages and capacity degrades over time, the only resolution is device replacement rather than a cell swap.
For experienced sub-ohm vapers who are clear on those trade-offs and value the endurance and protection the Armour Ultra offers, it is a well-executed device at its specific brief. All stock is held in the UK at WizVape and is available for immediate dispatch.
Finding the right coils for your Vaporesso Armour Ultra Vape Kit is essential for getting the best performance and flavour out of your device. There are 2 compatible options currently available, Vaporesso GTi Mesh Coils and Vaporesso Armour G Replacement Pods . Using the correct coils ensures optimal coil life, consistent vapour production, and the best possible flavour accuracy from your nic salts or e-liquids. Always make sure you're using genuine Vaporesso coils to avoid any compatibility or safety issues.
To put the Vaporesso Armour Ultra Vape Kit in context, here is how it stacks up against Vaporesso Armour G Pod Kit and Vaporesso Armour GS 80W Pod Vape Kit across the key specs that matter.
If you want to learn more about vape kits, how to choose the right coil resistance, and which nicotine salts and e-liquids work best with your setup, these guides are worth a read.
Think the Vaporesso Armour Ultra Vape Kit is the right kit for you? Pick one up below with fast UK delivery from WizVape.
No, the Armour Ultra is not suited to beginners. It is a 100W sub-ohm mod designed for experienced DTL vapers who understand wattage adjustment, coil priming, and e-liquid selection for high-output vaping. Beginners who are new to vaping or transitioning from a pod kit would be better served by a simpler device before moving to a high-wattage mod.
The Armour Ultra uses the GTi Dual Mesh coil platform. The kit includes a GTi 0.2Ω dual mesh coil pre-installed in the iTank T and a GTi 0.4Ω dual mesh coil as a spare. Replacement GTi coils are available from WizVape alongside the kit.
The 5500mAh internal battery delivers a full day of regular sub-ohm vaping at high wattage for most users. At moderate wattage on the 0.4Ω coil, endurance extends further. This capacity exceeds most single-cell external-battery mods and removes the need for a mid-day battery swap under typical use conditions.
High-VG freebase e-liquid at 3mg or 6mg nicotine strength is the correct choice for the GTi 0.2Ω and 0.4Ω coils. A 70/30 VG/PG blend or higher suits the 0.2Ω DTL coil. Nicotine salts are not appropriate for this device at any wattage setting, and 50/50 e-liquids are not recommended for the 0.2Ω coil at high output.
The Armour Ultra carries IP68 and IP69K ratings. IP68 certifies protection against sustained submersion beyond one metre. IP69K certifies resistance to high-pressure, high-temperature water jets, which is a more demanding standard than standard waterproofing ratings. The device also carries MIL-STD-810H military shock resistance certification and has been tested against drops of up to 1.2 metres.
The Vaporesso Armour Ultra is available from WizVape in UK stock in the TPD-compliant version with the 2ml iTank T. All products on WizVape are held in UK stock and comply fully with UK TRPR and TPD regulations.
No. Nicotine salts are not appropriate for use with the Armour Ultra at any wattage setting. Sub-ohm vaping at the wattages this device operates at produces a large volume of vapour per draw, and nicotine at 10mg or above creates an uncomfortably harsh throat hit in this format. High-VG freebase e-liquid at 3mg or 6mg is the correct choice.
Pulse Mode is an output setting on the AXON chipset that compensates for battery voltage drop by delivering power in rapid pulses to maintain a consistent effective output level. In practice this keeps the draw character more stable across the duration of a tank compared to standard fixed-wattage output, which can soften as the battery depletes.
F(t) Mode modulates the output over the duration of each draw, delivering higher power at the start of the draw and reducing it progressively. Vaporesso describe this as increasing flavour density. It is one of the output mode options accessible through the AXON chipset menu alongside standard wattage and Pulse Mode.
The iTank T is the sub-ohm tank bundled with the Armour Ultra kit. It features a top-airflow design that draws air in above the coil rather than at the base, which reduces the leaking risk common to bottom-airflow tanks during transport. The tank uses a top-fill mechanism and holds 2ml of e-liquid in the UK TPD-compliant version.
The Armour Ultra charges via the USB-C port at the base of the device. It supports fast charging at DC 9V/2A as well as a 5V/3A input. Using a cable and charger capable of the 9V/2A fast charge input will significantly reduce charge time compared to standard 5V charging on the 5500mAh cell. Battery level and charging progress are shown on the 0.96-inch TFT display.
The GTi 0.2Ω coil is the primary DTL option, producing denser, warmer vapour at higher wattage and best suited to fully open DTL draws with high-VG freebase e-liquid at 3mg or below. The GTi 0.4Ω coil runs at slightly lower wattage and provides a moderately less open RDTL draw, giving a different balance of warmth and airflow that some experienced sub-ohm vapers prefer for flavour detail.
Yes, the Armour Ultra has a 0.96-inch TFT colour display on the control face. It shows wattage, output mode, battery level as a percentage, coil resistance, and puff data. This gives a clear, precise readout of all relevant operating information without the need to interpret LED indicators.
No, the Armour Ultra is not suited to MTL vaping. It is a 100W sub-ohm mod designed around DTL and RDTL draw styles using the GTi 0.2Ω and 0.4Ω coils. MTL vapers should look at pod kits or lower-output devices with appropriate MTL coil options rather than a high-wattage mod of this type.
